2.5

Specification

General
Dimensions
Weight
Operational temperature
Storage temperature
Ingress protection rating
Relative humidity, max
Power supply
Nominal supply voltage
Current consumption, max
Display
Memory card
Built-in clock battery
Interfaces
LAN
Parameters
Bandwidth
Latency*, max
Jitter*, max
Device programming
Radio connection interfaces
MOTOTRBO
Non-MOTOTRBO
Inputs/outputs
Output type
Output current, max
Input voltage, max
* TRBOnet Enterprise/PLUS of version 5.2.5 and higher is required.
4
Table 2: TRBOnet Swift A200 Specification
82 x 34.5 x 102 mm
200 g
-20 °C to +60 °C
-40 °C to +85 °C
IP30
85% at +40 °C
12 V DC
0.5 A
OLED, mono color, 128 x 32 pix, 0.91 inch
MicroSD, 4 – 32 Gb
3 V, CR1220
7 I/O, micro-USB, USB, LAN, UART, Audio In/Out
RJ45, Ethernet 10/100Base-T, 10/100 Mbit/s
128 kbps for one voice connection
15 kbps for one control connection
1800 ms
400 ms
USB type B
USB (wired), NRF (wireless)
Audio (wired)
Open collector
100 mA
12 V
