About TRBOnet Swift A200
2.6
Design
FRONT PANEL
1
OLED display that shows the connection status and self-check information.
Micro-USB port to connect the device to a computer using the programming
cable.
REAR PANEL
1
DC power inlet.
Audio Input and Audio Output to connect a non-MOTOTRBO two-way radio.
Micro-Fit 3mm pitch connector to connect a non-MOTOTRBO radio, a 12V DC
power supply, and external hardware.
LAN port.
USB port to connect a MOTOTRBO radio.
2
3
4
2
5
5
