Setup and Connection
3.1.1
Configuring the A200 Gateway
To configure the A200 gateway:
Launch TRBOnet Swift CPS. In the main window, select USB as an interface for
device programming at the bottom (Figure 1). Connect the programming cable
to the micro-USB port of the A200 gateway and to a USB port of your computer.
If you prefer to program your A200 gateway using the LAN connection, select
LAN as the programming interface and connect the A200 gateway to the LAN
and to the power supply.
(Recommended) Update firmware of your A200 gateway:
a. Click Options on the Tools menu. In the right pane, make sure that the
Enable changing device mode option is switched on (Figure 2).
b. On the Device menu, click Update Firmware. If you use the LAN
connection for programming, specify the IP address of your A200 gateway
and click Connect.
c. In the Firmware update window, select your A200 gateway. Open the
Mode menu and click the preferred mode - "NRF RoIP Gateway" (for the
wireless connection to the radio) or "USB RoIP Gateway" (for the USB
connection to the radio).
d. On the Update to menu, select the latest firmware version. Click Update.
Figure 1: Selecting the USB connection for programming
Figure 2: The device mode change is enabled
9
