Setup and Connection
Wired (USB) connection with the radio
For the wired connection between the radio and A200 gateway, use the USB cable
supplied with the A200 gateway.
Note: Before connecting the A200 gateway to a MOTOTRBO two-way radio with the
USB cable, power off the radio and make sure that the A200 gateway is
disconnected from the power supply.
Connect the cable to the USB connector on the rear panel of the A200 gateway and
to the rear accessory connector of the radio.
Note: Once you have reconfigured the radio and/or option board, disconnect the
programming cable from the radio and reboot by powering off and on both
the A200 gateway and the radio.
Figure 10: The radio cable
15
