3.2

Non-MOTOTRBO Mode

To prepare TRBOnet Swift A200 for operation in the non-MOTOTRBO mode, follow
the steps in Table 7.
Table 7: High-level steps to prepare TRBOnet Swift A200 for operation in the non-MOTOTRBO mode
#
1 Assemble the service cable.
2 Update the firmware and configure your A200
gateway.
3 Update the configuration settings of the
radio.
4 Connect your A200 gateway to the radio and
to the LAN.
5 Connect your A200 gateway to the power
supply.
6 Power up the connected radio.
3.2.1 Assembling the Service Cable
The A200 gateway and a non-MOTOTRBO radio are connected using the service cable
and the audio cable. To assemble the service cable, use a Micro-Fit connector plug, a
wire kit, and a radio connector plug.
Note: The radio connector plug is not included in the delivery kit. Contact the
manufacturer of your radio or a sales representative to get the plug compatible
with the service connector of your radio.
To assemble the service cable:
Connect the wires to the Micro-Fit plug and to the radio connector plug to
implement the following required links:
Function
PTT
CSQ Detect
Ground
Note: The Micro-Fit connector pins are described in section
Connect the wires of the audio cable (provided in the delivery kit) to the radio
connector plug. Implement the following required links:
16
Step
Table 8: Service cable – required links
Micro-Fit plug
Any input pin (Pin 1 – Pin 7)
Any output pin (Pin 1 – Pin 6, Pin 8)
GND pin (black wire)
Refer to:
3.2.1 Assembling the Service Cable
16)
3.2.2 Configuring the A200 (page 18)
3.2.3 Configuring the Radio (page 20)
3.2.4 Connecting the Radio (page 20)
3.3 Power Supply (page 20)
Radio connector plug
Use pins as advised in the
documentation of the radio.
2.7 Connectors
TRBOnet Swift A200 – User Manual
(page
(page 6).
