Generating a script Deutschmann Automation GmbH & Co. KG
8.6

The use of the Protocol Developer

The Protocol Developer is a tool for an easy generation of a script for our script gateways. Its
operation is exactly aimed at this use. After starting the program the script that was loaded the
last time is loaded again, provided that it is not the first start.
Typical for Windows script commands can be added by means of the mouse or the keyboard. As
far as defined and required for the corresponding command, the dialog to the corresponding
command is displayed, and after entering the values the right text is automatically added to the
script. The insertion of new commands by the Protocol Developer is carried out in a way that
existing commands will not be overwritten. Generally a new command is inserted in front of the
one where the cursor is positioned. Of course the commands can also be written by means of the
keyboard or already written commands can also be modified.
®
30 Instruction manual UNIGATE IC - EtherNet/IP 2Port V. 1.8 8.2.16
