12 EtherNet/IP

If you are speaking of EtherNet/IP, then the CIP about Ethernet is meant. The end device's proto-
col is being converted in the UNIGATE
12.1

Data exchange mode

The gateway has to be in the data exchange mode, so that a data exchange between the RS-
side of the gateway and the fieldbus is possible. This mode is always avtive as long as the gate-
way is not in the configuration mode, the firmware update- or Debugmode. In the data exchange
mode the gateway will carry out the downloaded Script.
12.2

EtherNet/IP address-assignment

The Ethernet/IP address can either be assigned through WINGATE, the Script or via DHCP.
12.3

Project planning

Use any project planning tool for project planning.
A sample EDS-file can be found on the Internet (www.deutschmann.com) free of charge. Gener-
ating the EDS-file is also provided as service from Deutschmann Automation.
12.4

Possible data lengths

The table below shows the maximum transferable data:
Input data
Output data
12.5

Literature

We recommend the book "The Common Industrial Protocol and the Family of CIP Networks"
(PUB 00123RO), to help you quickly get to grips with the subject of Ethernet/IP. The book can be
ordered from the ODVA User Organisation (web: www.odva.org).
