Deutschmann Automation GmbH & Co. KG
9

FTP-Server

®
This UNIGATE features an integrated FTP-Server, which allows access to the file system of the
device. The FTP-Server is password protected. With the predefined user name "deutschmann"
and the password "deutschmann" a connection can be established. The login data can be
defined by setting the Script parameters „FTP_Password" and „FTP_UserName".
Note: On write access to the file system the actual write process to the non-volatile memory is
taking place delayed (5 seconds after the last write access to the file system or when disconnect-
ing the FTP connection). Before restarting the device one must wait for the write process to the
non-volatile memory to complete to prevent data loss.
9.1

Script-update via FTP

In the Protocol Developer save the compiled script (DCS file) using the file name
"script.dcs". Transfer the file to the UNIGATE
disconnect from the FTP server and restart the device. Upon device startup the UNIGATE
over the script contained in the file and deletes the file afterwards.
9.2

System configuration update via FTP

In WINGATE save the configuration (GWC file) using the file name "system.gwc". Transfer the
®
file to the UNIGATE . After completion of the write process, please disconnect from the FTP
server and restart the device. Upon device startup the UNIGATE
contained in the file and deletes the file afterwards.
8.2.16 Instruction manual UNIGATE
®
. After completion of the write process, please
®
takes over the configuration
®
IC - EtherNet/IP 2Port V. 1.8
FTP-Server
®
takes
