Connections

Both the MKIV H and MKIV D cameras have a
12 pin Binder connector that carries all power
and comms signals.
The pinout for this connector is detailed in the
table on the right.
The D-Type connector which is part of the
power/comms cable is wired to connect directly
to a controlling PC. The D-Type pinout detailed
in the table below is consistent with this.
Connector Information.
Mating half : Binder 720 female, 12 pin P/N 99-9134-02-12
D-Type Pinout
Pin
2
3
5

Specifications

Camera Sensor
Camera Sensitivity
Camera Resolution
SNR
Field of View
Zoom
User Presets
Lens Drive Train
