Camera User Manual
Surveillance Camera User Manual
Subject to change without notice
Visual Engineering Technologies Ltd.
4.3.2013 v1_2
VISUAL ENGINEERING LTD
Unit 3, Griggs Business Centre,
West Street,
Coggeshall,
Essex CO6 1NT
UK
Phone: +44 (0) 1376 564024
Email: sales@visualengineering.co.uk
E&OE
Advertisement
Table of Contents
Related Manuals for visual engineering MKIIID
Summary of Contents for visual engineering MKIIID
- Page 1 Camera User Manual Visual Engineering Technologies Ltd. Surveillance Camera User Manual 4.3.2013 v1_2 VISUAL ENGINEERING LTD Unit 3, Griggs Business Centre, West Street, Coggeshall, Essex CO6 1NT Phone: +44 (0) 1376 564024 Email: sales@visualengineering.co.uk Subject to change without notice E&OE...
-
Page 2: Table Of Contents
About the User Manual...........................5 Warranty and Support ..........................5 Introduction to the Visual Engineering line of Surveillance Cameras ............6 MKIIID: 18 – 36 X Optical Zoom, IP67 PTZ Camera ................6 MKIIIH: High Definition IP67 PTZ Camera ..................7 MKIXB: 36X Optical Zoom Forward Centre Camera................8 MKX: Micro Forward Center Pan and Tilt Camera ................8... - Page 3 Camera User Manual Visual Engineering Technologies Ltd. Camera Specifications........................24 Camera Interfaces..........................25 Camera Dimensions ..........................27 MKIIID............................27 MKIIIH............................27 MKIXB............................28 MKX...............................28 SWZ ...............................29 PPTZ-025010 ..........................29 COS-XXX-XX ...........................30 PHC-XXX-X .............................30 Subject to change without notice E&OE...
-
Page 4: Change History
Camera User Manual Visual Engineering Technologies Ltd. Change History Version Date Change Summary Author V1.0 23.2.2012 V1.2 5.3.2013 Checks and amendments for Pin Hole Zoom Camera Subject to change without notice E&OE... -
Page 5: About The User Manual
Camera User Manual Visual Engineering Technologies Ltd. About the User Manual This user manual describes the operation of the Visual Engineering line of dedicated surveillance cameras. The user manual is split into two sections. Section one is the user guide, in which the reader is introduced to the full range of cameras, and their function. -
Page 6: Introduction To The Visual Engineering Line Of Surveillance Cameras
Visual engineering cameras can be recognised from their equipment label, the following part numbers are described in this document: MKIIID: 18 – 36 X Optical Zoom, IP67 PTZ Camera MKIIIH: High Definition IP67 PTZ Camera MKIXB: 36X Optical Zoom Forward Centre Camera... -
Page 7: Mkiiih: High Definition Ip67 Ptz Camera
Camera User Manual Visual Engineering Technologies Ltd. is accomplished via Sony VISCA over RS232. VE manufacture a range of controller / monitors compatible with this camera. Other control protocols are available on request. The outer casing is manufactured from Delrin, shot blasted to reduce reflections and coated to prevent moisture ingress. -
Page 8: Mkixb: 36X Optical Zoom Forward Centre Camera
Camera User Manual Visual Engineering Technologies Ltd. MKIXB: 36X Optical Zoom Forward Centre Camera The MKIXB is around the latest generation, low light, Sony block cameras. The MKIXB forward centre PTZ allows a +/- 30 degrees range of motion in both pan and 25 degrees in tilt. -
Page 9: Cos-X-Xx: Micro Head Camera Flexible Or Semi Rigid
Camera User Manual Visual Engineering Technologies Ltd. camera to rotate around a point in space centred on the pinhole lens’s focal point. Using this method the camera aperture can be <2mm, whilst allowing the camera to move +/- 30° in both pan and tilt. - Page 10 Camera User Manual Visual Engineering Technologies Ltd. (sometimes referred to as a ‘snake’ camera). As standard cables lengths are 300mm, although custom lengths can be prepared. The maximum semi-rigid length is 1m. As part of the Visual Engineering security products line, the camera is compatible with all our monitors and controllers.
-
Page 11: Phc-Xxx: Micro Pin Hole Cameras 15 - 70Mm
Camera User Manual Visual Engineering Technologies Ltd. PHC-XXX: Micro Pin Hole Cameras 15 – 70mm The PHC Micro Pinhole cameras, combine a pinhole lens with a miniature SOC sensor allowing rapid deployment in any situation. The device incorporates a tiny, system-on-chip (SOC) sensor, and it’s necessary ancillary circuitry into a weatherproof package measuring just 43x12x12mm. -
Page 12: Swz: Miniature Pan And Tilt Camera
Camera User Manual Visual Engineering Technologies Ltd. SWZ: Miniature Pan and Tilt Camera The SWZ is designed to provide a switched zoom function pan & tilt assembly, in a small lightweight package. As well as surveillance, the switched zoom is also perfect for UAV integration applications. -
Page 13: Pptz-025010 Pin Hole Pan Tilt Zoom Camera
Camera User Manual Visual Engineering Technologies Ltd. PPTZ-025010 Pin Hole Pan Tilt Zoom Camera The PPTZ" designed to allow +/- 30 degree pan and tilt range along with 2.5- 10mm zoom. All this through a 2mm discreet aperture. The device incorporates a low light high resolution colour Camera a pin hole zoom lens and smooth low noise pan and tilt drives along with the necessary drive train and control electronics. -
Page 14: Dmmptzc: Digital Multi Meter Controller For Ptz
Camera User Manual Visual Engineering Technologies Ltd. HHC forms the core of a new group of control and monitoring hardware from Visual Engineering. We are aware that there is no one size fits all for field applications. As such we have designed a range of controllers and monitors that can be used either alone, or in conjunction with other items from the range to build an application specific control solution. -
Page 15: Recognition Ranges
Camera User Manual Visual Engineering Technologies Ltd. The DMMPTZC provides the perfect accompaniment for VE’s range of near-field covert cameras. Developed in response to law enforcement requirements for covert installation test equipment , the DMMPTZC provides a full test kit that can be hidden in plain sight. - Page 16 Camera User Manual Visual Engineering Technologies Ltd. Number Plate Recognition: Requires 15 pixels across 10cm horizontally Using the methods described above and practical experimentation; the following identification ranges can be achieved Model Lens Facial ID Number plate ID MKIIID 120m...
-
Page 17: Low Light Performance
Camera User Manual Visual Engineering Technologies Ltd. PHC-030 PHC-045 PHC-070 PPTZ-025010 Low Light Performance Because much surveillance is performed in low light, the low light performance of the camera is critical. Many of the Visual Engineering cameras have excellent low light characteristics. -
Page 18: Operating The Cameras
Camera User Manual Visual Engineering Technologies Ltd. 0.004 PPTZ-025010 0.12 Operating the Cameras The Pan and Tilt capable cameras from Visual Engineering are controlled using RS232 interface as standard, the Sony VISCA protocol is employed for this control. The baud rate of the RS232 is 9K6 for all the cameras. -
Page 19: The Pc Controller
Camera User Manual Visual Engineering Technologies Ltd. The PC Controller The PC controller is available free of charge and can be down loaded from the Visual Engineering website at www.visualengineering.co.uk. The PC controller application is ‘90002-3-001 VE Visca Controller V1.0.0.x Download’ The PC controller should be loaded onto a PC with an RS232 control port, or a RS232 USB adaptor. -
Page 20: The Hand Controller
Camera User Manual Visual Engineering Technologies Ltd. The Hand Controller Connect the hand controller to the camera using the cable provided. The hand controller should be connected to a suitable power source, the power source will power the camera and the controller. -
Page 21: The Multi-Meter Controller
Camera User Manual Visual Engineering Technologies Ltd. Rear Button 3 and Rear Button 4 pressed together toggles the manual / auto focus function. The Multi-Meter Controller Ensure the Multi-Meter controller is fully charged, by connecting the AC adaptor. Charging fully can take 3 hours. -
Page 22: Installing The Cameras
SWZ: Miniature Pan and Tilt Camera Outdoor Mounting Kits The MKIIID, MKIIIH and SVZ are each provided with a ¼’’-20 UNC tripod mount screw, these can be mounted to any commercial tripod or mount. Visual Engineering can provide specialist mounting kits if required, users should contact sales at Visual Engineering for more details. - Page 23 Camera User Manual Visual Engineering Technologies Ltd. PHC-XXX: Micro Pin Hole Cameras 15 – 70mm PPTZ-025010: Pin Hole Pan Tilt Zoom These pin hole based cameras are usually built into hides or concealments. The MKIXB is particularly used in covert vehicles, while the MKX is used typically concealed in room furniture.
-
Page 24: Technical Section
Camera User Manual Visual Engineering Technologies Ltd. Technical Section Camera Specifications MKIIID MKIIIH MK1XB PPTZ COS-XX PHC-XX Binder 12w Binder 12w Binder 8w Binder 8w Binder 8w Binder Binder Binder Interfaces Horizontal 360 degree 360 degree 60 degree 60 degree... -
Page 25: Camera Interfaces
Camera User Manual Visual Engineering Technologies Ltd. Camera Interfaces The cameras are provided with one of two interface connectors, an 8 pin or 12 pin Binder. The interface has the following pin out. VE 12 Pin camera connection. Mating half : Binder 720 female, 12 pin P/N 99-9134-02-12... - Page 26 Camera User Manual Visual Engineering Technologies Ltd. Mating half : Binder 720 female, 12 pin P/N 99-9134-02-12 Pin Out Subject to change without notice E&OE...
-
Page 27: Camera Dimensions
Camera User Manual Visual Engineering Technologies Ltd. Camera Dimensions MKIIID MKIIIH Subject to change without notice E&OE... -
Page 28: Mkixb
Camera User Manual Visual Engineering Technologies Ltd. MKIXB Subject to change without notice E&OE... -
Page 29: Swz
Camera User Manual Visual Engineering Technologies Ltd. PPTZ-025010 Subject to change without notice E&OE... -
Page 30: Cos-Xxx-Xx
Camera User Manual Visual Engineering Technologies Ltd. COS-XXX-XX PHC-XXX-X Subject to change without notice E&OE...
