UG-835

GETTING STARTED

EVALUATION BOARD SETUP PROCEDURE

The EVAL-ADG5248FEBZ evaluation board operates
independently and does not require any additional evaluation
boards or software to operate. An on-board LDO regulator is the
digital power supply for the LEDs and manually controls the
ADG5248F.
Supply the evaluation board with a dual power source of up to
±22 V or a single supply of up to 44 V by connecting V
GND together.
POSFV
VDD
R20 = LDO
R21 = EXT_VL
EXT_VL
GND
VSS
NEGFV
and
SS
J4
J3
ADP7142
(LDO)
SW1
SW2
J3
SW3
SW4
J3
J4
Figure 2. EVAL-ADG5248FEBZ
EVAL-ADG5248FEBZ User Guide
Set up a simple functionality test as follows:
1. Connect a power supply to J3. Connect VSS and GND
together if a single supply is required.
2. Ensure a 0 Ω resistor is inserted in R18 to use the on-board
LDO regulator, and that a 0 Ω resistor inserts into R20. SW1
through SW4 control the digital signals for the ADG5248F.
3. LED1 and LED3 illuminate green to indicate that the
multiplexer is operating normally.
R34 = POSFV
R39 = VDD
V POSFV
DD
ADG5248F
J1:S1
S1
J1:S8
S8
EN/F2
A0/F0
FAULT DETECTION
A1/F1 AND
SWITCH DRIVER
A2
V
GND NEGFV
SS
R35 = VSS
R40 = NEGFV
Block Diagram
Rev. A | Page 4 of 14
VL
R41 = VL
J2:D
D
FF
LED
SF
LED
R42 = GND
