EVAL-ADG5248FEBZ User Guide

BILL OF MATERIALS

Table. 3
Reference Designator
A0/F0, A1/F1, A2, EN/F2
C1 to C3, C6, C9, C13 to C15
C4, C5, C11, C12
C7, C8
D1
FF, SF
GND1, GND2
J1
J2, J4
J3
LED1, LED3
LED2, LED4
Q1 to Q4
R1 to R3, R7 to R9, R12, R13, R16, R19,
R23, R28, R37, R49, R50, R54 to R57
R4 to R6, R10, R11, R17, R22, R24 to R27,
R29, R30 to R33, R43 to R45
R14, R36, R47, R48
R15, R38, R46, R51 to R53
R18, R20, R35, R39
R21, R34, R40 to R42
S1 to S8
SW1 to SW4
T1 to T9
T_A0 to T_A2, T_EN, T_FF, T_SF
U1
U2
Description
50 Ω straight SMB jacks
50 V, X7R, multilayer ceramic capacitors,
0603 size, 0.1 µF
50 V tantalum capacitors, D size, 10 µF
Ceramic multilayer capacitors, 4.7 µF
50 Ω SMB socket
50 Ω straight SMB jacks
Black test points
8-pin terminal block (5 mm pitch)
2-pin terminal blocks (5 mm pitch)
4-pin terminal block (5 mm pitch)
LEDs, SMD green, 0805
LEDs, SMD red, 0805
Transistors, N-MOSFET, 60 V, 0.23 A, SOT-23
Resistors, 0603, 1%, 0 Ω
SMD resistors, 0603
Resistors, 300 Ω, 0.1 W, 1%, 0805
Resistors, 1 kΩ, 0.063 W, 1%, 0603
Resistors, 0805, 1%, 0 Ω
SMD resistors, 0805
50 Ω, SMB sockets
SPDT, SMT slide switches
Red test points
Red test points
Fault protection and detection, 1 pC Q
8:1 multiplexer
Linear regulator, 5.0 V, LDO
Rev. A | Page 13 of 14
Part Number
SMB1251B1-3GT30G-50
GRM188R71H104KA93D
TAJD106K050RNJ
C2012X5R1H475K125AB
SMB1251B1-3GT30G-50
SMB1251B1-3GT30G-50
20-2137
CTB5000/8
CTB5000/2
CTB5000/4
KP-2012SGC
KP-2012SRC-PRV
BSS138N
MC0063W06030R
Not applicable
MC01W08051300R
MC0063W060311K
MC01W08050R
Not applicable
SMB1251B1-3GT30G-50
CAS-120TA
20-313137
20-313137
, ADG5248FBRUZ
INJ
ADP7142AUJZ-5.0
UG-835
Stock Code
FEC 1111349
FEC 882-0023
FEC 143-2387
FEC 2346932
Do not insert
FEC 1111349
FEC 873-1128
FEC 9633014
FEC 151789
FEC 151791
FEC 1318243
FEC 1318244
FEC 115-6434
FEC 9331662
Do not insert
FEC 9332987
FEC 9330380
FEC 9333681
Do not insert
Do not insert
Digi-Key CAS120JCT-ND
FEC 873-1144
FEC 8731144
ADG5248FBRUZ
ADP7142AUJZ-5.0-R7
