Menu Commands

Video Menu

The IN1402 allows you to manually adjust the brightness, contrast, color, hue, sharpness, gamma,
noise filter, and comb/trap filter settings.
To access the video adjustment menu via the front panel control buttons
1. Press the desired INPUT SELECT button.
2. Press MENU.
3. Press the or button (if necessary) to reach the video menu.
Press ENTER.
4.
Use the and buttons and the ENTER key to select the setting you wish to adjust.
5.
6. After selecting a setting, use the
7. Press and release a button to move one step in either direction.
8. Press and hold a button to move continuously through the adjustment range.
9. Press ENTER to save when the input is optimized.
It is critical that you save the setting before proceeding to another input or another menu function,
otherwise your new adjustment will be lost.
The following video adjustment parameters can be controlled via the on-screen menu system (front
panel buttons). Remote operation instructions can be found on page 16.
Brightness Setting adjusts the input signal brightness.
Range: 0 to 255
Factory default setting: 128
Operation:
Press button to increase the brightness.
Press button to decrease the brightness.
Contrast adjusts the difference between the input signal's brightest and darkest settings.
The minimum setting displays at about the same brightness (very grayish). The maximum setting
displays a noticeable difference between the darkest and lightest parts of the screen.
Range: 0 to 255
Factory default setting: 128
Operation:
Press button to increase the contrast.
Press button to decrease the contrast.
Color adjusts the color saturation of the picture over a wide range. Setting this control to 0 removes
most of the color.
Range: 0 to 255
Factory default setting: 140
Operation:
Press button to increase the color.
Press button to decrease the color.
and buttons to make the adjustments.
IN1402 User's Manual 7
