Extron electronics IN1402 User Manual page 20

Command
HUExxx set hue to absolute value (000-040)
HUE? return current hue
INFO? return unit version
NOISE+ increase noise filter
NOISE- decrease noise filter
NOISE@ set noise filter to normal (009)
NOISExxx set noise filter to absolute value (000-047)
NOISE? return current noise filter
PH+ increase horizontal position
PH- decrease horizontal position
PH@
set horizontal position to normal**♦
PHxxx
set horizontal position to absolute value♦
PH? return current horizontal position
PV+ increase vertical position
PV- decrease vertical position
set vertical position to normal** ♦
PV@
PVxxx
set vertical position to absolute value♦
PV? return current horizontal position
RES000 factory reset
RES1 reset video
RES3 reset input
RES4 reset output
RES5 reset RS-232
SAT+ increase color
SAT- decrease color
SAT@ set color to normal** (140)
SATxxx set color to absolute value (000-255)
SAT? return current color
SCS0 set resolution to 640 x 480**
* The commands are not case sensitive.
** Default values when factory reset is performed.
♦ Normal and available values depend on the current output mode.
18
Description
IN1402 User's Manual
Command
SCS1 set resolution to 800 x 600
SCS2 set resolution to 852 x 480
SCS3 set resolution to 1024 x 768
SCS4 set resolution to 1152 x 864
SCS5 set resolution to 1280 x 720
SCS6 Set resolution to 1280 x 768
SCS7 set resolution to 1280 x 1024
SCS8 set resolution to 1365 x 768
SCS9 set resolution to 1365 x 1024
SCS? return current resolution
SH+ increase horizontal size
SH- decrease horizontal size
SH@ set horizontal size to normal**(100)
SHxxx
set horizontal size to absolute value (♦-100)
SH? return horizontal size
SHP+ increase sharpness
SHP- decrease sharpness
SHP@ set sharpness to normal** (003)
SHPxxx set sharpness to absolute value (000-008)
SHP? return current sharpness
SV+ increase vertical size
SV- decrease vertical size
SV@ set vertical size to normal**(100)
SVxxx
set vertical position to absolute value (♦-100)
SV? return vertical size
SYNC0 set output sync to RGBHV- -**
SYNC1 set output sync to RGBHV+ +
SYNC2 set output sync to RGBS
SYNC4 set output sync to RGsB
SYNC? return current output sync
Description
