On-screen menu

To access the main menu, press the MENU or ENTER button. Use the arrow buttons to maneuver
around within the menu display. Press ENTER to select and save a command, or press MENU to
escape to the previous menu or to clear the menu display. All audio, video, input, and output settings
for each input and each output mode are stored internally (in memory) so the adjustments will not
have to be repeated after they are optimized.
The Main Menu commands and their functions are:
Video: Changes input signal video parameters.
Audio: Changes input signal audio parameters.
Input: Changes input signal timing format parameters.
Changes output signal resolution and format parameters.
Output:
Advanced: Displays advanced options.

Menu Commands

Video menu

The IN1404 allows you to manually adjust the brightness, contrast, color, hue, sharpness, gamma,
noise filter, and comb/trap filter settings.
To access the video adjustment menu via the front panel control buttons
1. Press the desired Input Select button.
2. Press MENU.
3. Press the or button (if necessary) to reach the video menu.
4. Press ENTER.
Use the and buttons and the ENTER key to select the setting you wish to adjust.
5.
6. After selecting a setting, use the
7. Press and release a button to move one step in either direction.
8. Press and hold a button to move continuously through the adjustment range.
9. Press ENTER to save when the input is optimized.
CAUTION
It is critical that you save the setting before proceeding to another input or another menu
function; otherwise, your new adjustment will be lost.
The following video adjustment parameters can be controlled via the on-screen menu system (front
panel buttons). Remote operation instructions can be found on page 29.
Brightness setting adjusts the input signal brightness.
Range: 0 to 255
Factory default setting: 128
Operation:
Press button to increase the brightness.
Press button to decrease the brightness.
10
and buttons to make the adjustments.
