When controlling multiple units, the Controller Receiver Terminal must connect to only one
IN1402 Transmit Terminal. Multiple IN1402 Transit Lines may not be connected together;
otherwise signal contention from multiple units will result. Therefore, "receive" information is
only available from one IN1402 in this configuration. Each unit must be set to different
delimiters.

IN1402 serial commands*

Command
ACI3 set baud rate to 1200
ACI4 set baud rate to 2400
ACI5 set baud rate to 4800
ACI6 set baud rate to 9600**
ACI7 set baud rate to 19,200
ACI8 set baud rate to 38,400
ACI9 set baud rate to 57,600
ACI? return current baud rate
ASP0 set aspect ratio to standard**
ASP1 set aspect ratio to anamorphic
ASP2 set aspect ratio to wide screen
ASP3 set aspect ratio to wider screen
ASP4 set aspect ratio to expand
ASP? return current aspect ratio
BRG+ increase brightness
BRG- decrease brightness
BRG@ set brightness to normal** (128)
BRGxxx set brightness to absolute value (000-255)
BRG? return current brightness
CH1 select channel 1
CH2 select channel 2
CH3 select channel 3
CH? return current channel
CMDCD0 set delimiters to brackets [ ]**
CMDCD1 set delimiters to braces { }
CMDCD2 set delimiters to parentheses ( )
CMDCD3 set delimiters to less and greater < >
* The commands are not case sensitive.
** Default values when factory reset is performed.
♦ Normal and available values depend on the current output mode.
Description
IN1402 User's Manual
Command
CMDCD4 set delimiters to slashes \ /
CMDCD5 set delimiters to signs !#
CMDCD? return current delimiters
CON+ increase contrast
CON- decrease contrast
CON@ set contrast to normal** (128)
CONxxx set contrast to absolute value (000-255)
CON? return current contrast
CTF0 select comb filter**
CTF1 select trap filter
CTF? return current comb / trap filter state
FP toggle front panel controls
FP0 disable front panel controls
FP1 enable front panel controls**
FP? return current front panel state
GAM+ increase gamma
GAM- decrease gamma
GAM@ set gamma to normal**(010)
GAMxxx set gamma to absolute value (001-030)
GAM? return current gamma
HTK0 set horizontal tracking to very fast
HTK1 set horizontal tracking to fast**
HTK2 set horizontal tracking to normal
HTK3 set horizontal tracking to slow
HTK? return current horizontal tracking
HUE+ increase hue
HUE- decrease hue
HUE@ set hue to normal** (020)
Description
