Order Information
standard temperature range Industrial
PcieBiSerialDb37BA22
Order Options:
Pick any combination to go with IO
-CC
-ET
Dbterm37:
Dbcabl37:
PCIe BiSerial DB37 BA22 Eng Kit :
All information provided is Copyright Dynamic Engineering
PCIe Module with Transmitter and Receiver .
[2 bit serial image data plus sync and clock]
http://www.dyneng.com/pciebiserialdb37.html
to add conformal coating
to change to industrial Temp [-40 - +85C]
37 position terminal block with DB37
connector.
http://www.dyneng.com/DBterm37.html
DB37 cable compatible with
PCIeBiSerialDB37. Twisted pairs on correct
pin pairs.
http://www.dyneng.com/DBcabl37.html
Windows Driver software, Loop-Back Plug,
reference schematics. Recommended for first
time purchases.
http://www.dyneng.com/pciebiserialdb37.html
