lines per frame [Frame Length], and the repetition rate. The Blanking time is the
difference in the frame repetition rate and the size of the image and idle time. It is
programmed in terms of the reference rate clock. The time does not have to be an
integer number of pixels.
Please see the register definitions for more detail.
Embedded Solutions
Page 13
