PCIe Module Front Panel IO Interface Pin Assignment

The figure below gives the pin assignments for the IO Interface on the
PcieBiSerialDb37BA22.
IO_0p (TxPSync+)
IO_1p (TxPDataU+)
IO_2p (TxPDataL+)
IO_3p (TxPClk+)
IO_4p (RxPSync+)
IO_5p (RxPDataU+)
IO_6p (RxPDataL+)
IO_7p (RxPClk+)
IO_8p (unused)
IO_9p (unused)
IO_10p (unused)
IO_11p (unused)
IO_12p (unused)
IO_13p (unused)
IO_14p (unused)
IO_15p (unused)
IO_16p (unused)
IO_17p (unused)
GND*

Figure 25 PcieBiSerialDb37BA22 FRONT PANEL Interface

GND is shunt selectable for DC, AC and open configurations. Jumper is located near
lower edge of DB37 connector. Options labeled in silk-screen
IO_0m (TxSync-)
IO_1m (TxDataU-)
IO_2m (TxDataL-)
IO_3m (TxClk-)
IO_4m (RxPSync-)
IO_5m (RxPDataU-)
IO_6m (RxPDataL-)
IO_7m (RxPClk-)
IO_8m (unused)
IO_9m (unused)
IO_10m (unused)
IO_11m (unused)
IO_12m (unused)
IO_13m (unused)
IO_14m (unused)
IO_15m (unused)
IO_16m (unused)
IO_17m (unused)
