Configure the Trusted Network

The DHCP Server option sets the SOHO 6 Wireless to assign IP
addresses to the computers on the trusted network. The SOHO 6
Wireless uses DHCP to make the assignments. When the SOHO 6
Wireless receives a request from a new computer on the trusted
network, the SOHO 6 Wireless assigns the computer an IP address.
If you use a DHCP server to assign IP addresses, enable the DHCP
Relay option. This option causes the SOHO 6 Wireless to forward
the DHCP request to the specified DHCP server.
Configure DHCP server and DHCP relay
To configure DHCP server:
1 Type the IP address of the trusted network in your browser
window to connect to the System Status page of the SOHO 6
Wireless:
The default IP address is: http://192.168.111.1
2 From the navigation bar on the left side, select
Network => Trusted.
The Trusted Network configuration page opens.
