Follow these steps to configure a pass through:
1 Type the IP address of the trusted network in your browser
window to connect to the System Status page of the SOHO 6
Wireless:
The default IP address is: http://192.168.111.1
2 From the navigation bar on the left side, select
Firewall => Pass Through.
The Unrestricted Pass Through IP Address page opens.
3 Set the Enable pass through address check box.
4 Type the IP address of the computer to connect to the pass
through. This must be a public IP address.
The illustration shows a pass through address of 206.253.208.103.
5 Click Submit.
A pass through connection decreases the security of the trusted network,
because the computer with the pass through connection is on the same
Ethernet segment as the trusted network. Do not use a pass through
connection unless the effect of the pass through connection on the security
of the trusted network is known.
User Guide
Create an Unrestricted Pass Through
N
OTE
83
