Muvpn Clients - Watchguard Firebox SOHO 6 Wireless User Manual

To set up split tunneling follow these steps:
1 Type the IP address of the trusted network in your browser
window to connect to the System Status page of the SOHO 6
Wireless:
The default IP address is: http://192.168.111.1
2 From the navigation bar on the left side, select
VPN => Manual VPN.
The Manual VPN page opens.
Click Add.
3
The Add Gateway page opens.
4 Configure the gateway.
See Figure , "Set Up multiple SOHO-SOHO VPN tunnels," on page 111
for information about the Add Gateway page.
5 Set the network IP address of the Local Network.
6 Set the IP address of the Remote Network.
7 Click Submit.

MUVPN Clients

The MUVPN Clients allows remote users to connect to the SOHO 6
Wireless through a secure (IPSec) VPN tunnel. This option allows
remote users to connect to the SOHO 6 Wireless through an IPSec
VPN tunnel. The MUVPN client creates an encrypted tunnel,
protected behind a SOHO 6 Wireless, to your trusted or optional
network depending on if it is a wired or wireless connection. A
wired connection goes to the trusted and the wireless connection
goes to the optional.
If you have a wireless network, you can configure the wireless
network to require wireless computers to have an encrypted
MUVPN connection to access the SOHO 6 Wireless. The SOHO 6
Wireless includes several MUVPN client licenses. For more
