Tally Dascom 5130P
X X
Self-Test (Font and Codepage Test Page)
With the cover closed, hold USER1 at power-on till the printer resets to activate the Self-Test. Single
mode: Load an A4 to start the self-print.
Tractors mode: Paper will auto load and start print.
The format of Self-Test follows 1xxx format :Print Font- and/or Codepage test page
Self-Test (Endless Running ASCII Tree)
With the cover closed, hold OFFLINE at power-on till the printer resets to activate the Self-Test. Load an
A4 to start the self-print.
Single mode: Load an A4 to start the self-print.
Tractors mode: Paper will auto load and start print.
The format of Self-Test follows 1xxx format: Endless running ASCII (tree form)
Self-Test (Configuration with Menu Settings)
With the cover closed, hold USER2 at power-on till the printer resets to activate the Self-Test.
Single mode: Load an A4 to start the self-print.
Tractors mode: Paper will auto load and start print.
L1 and L2 light up.
The format of Self-Test follows 1xxx format: Logo, model, FW+CG versions, head integrity, and current
configurations

Hex Dump

1) With the cover closed, hold USER1 and OFFLINE at power-on. L2 is on; L3 and L5 are blinking. The
printer resets and turns off L3 and L5 to indicate the activation of Hex Dump.
2) Hex Dump format is same as 1xxx.
3) Terminate Hex Dump by switching off the printer.
●
Enable/Skip listing of
current settings
●
System Setup
●
I/F Setup
●
ESC/P2 Emulation
●
IBM X24 Emulation
●
Restore Factory
Defaults
Hex-Dump
