Printer Components

Component
Control Lever
Paper Loader
Print Head
Cover
Control panel
Power switch
Ribbon cartridge
Ribbon guides
Power receptacle
Serial interface
Parallel interface
USB interface
Function
Lift up the top of mechanism to install or remove ribbon
Paper feed path for single sheet and passbook.
24-pin printing mechanism
Protects print head and other components inside, and reduces noise.
Shows printer status, and for printer setup
Power printer ON or OFF
Contains the ink to print on the media
For guiding ribbon installation on print head
Connects power cord to the printer
Connects serial interface cable from the host
Connects parallel interface cable from the host
Connects USB interface cable from the host
