Tractor Pair Installation
If you want to use continuous fanfold paper, you have to install the tractor pair assembly. Before installing the
tractor pair assembly, the printer rear cover must be removed first. Below instructions show how to install
and remove both the printer rear cover and tractor pair assembly.
Removing and installing the printer rear cover:
1. Ensure there is no loaded paper in the printer. Switch off the printer.
2. Open the printer top cover, move the print head with care to the left. Attention: The print head could be
very hot if printing had just been performed, so be careful when touching the print head.
3. Use a flathead screwdriver or similar tool to insert into the latches at "4" and "5", apply downward
pressure to release the lock. Remove the rear cover "6" from the back of the printer. Close the printer top
cover.
4. Installing the printer rear cover is the reverse of the removal process. First, align the latches of the rear
cover at the back of the printer. Next, use your thumbs to press the rear cover steadily and firmly towards
the printer. The "4" and "5" latches should snap on. When the installation is done correctly, the rear cover
should be flat against the back of the printer.
