Firmware Update - Tally Dascom 5130P User Manual

Tally Dascom 5130P

Firmware Update

Sometimes it is necessary update the firmware to solve a problem. The latest firmware file may be obtained
from your dealer or downloaded from our website www.dascom.com. Before upgrading firmware, it is
strongly recommended to print the Main Menu page to keep a record of the old settings.
Note: Firmware update should only be performed by an authorized service person. We disclaim any
responsibility for any damage caused if it is performed by any other person.
To load new firmware, please proceed the following steps:
1. Open the cover
2. Press User 1 + Offline and Power ON the printer.
3. L1 and L2 are blinking alternatively.
4. COPY /B <filename>.mot PRN
Note: Do not interrupt the downloading process to prevent possible flash memory corruption.
5. When downloading is completed, the carriage returns to home position. Printer initializes normally.
38
