Notes on Ribbon Cartridge Removal:
1. Eject any paper loaded in the printer.
2. Turn off the printer power.
3. Open the front cover.
4. Move the carriage to the middle. Be careful not to touch the print head if printing had just been performed,
as the print head may be hot.
5. Remove the blue ribbon guides from the print head.
6. Use fingers to take hold of the ribbon cartridge firmly, and pull the cartridge towards you to unlatch it.
7. Remove the ribbon fabric from the print head carefully without entangling it.

Connecting the Interface Cable

The parallel, serial and USB interface ports are located at the rear of the printer. Choose the interface which
suits your system. IMPORTANT: Make sure the printer and the computer are switched off before connecting
or disconnecting the interface cable to prevent electrical damage to the interface ports.
USB Interface
Parallel Interface
Serial Interface
