Alcatel-Lucent CellPipe 7130 Manual page 62

Network
............................................................................................................................................................................................................................................................
Fields
Untagged
Always use ID
User Name
Password
Access Concentrator
Service Name
Mode
Connect on demand: Max idle time
Always on
Manual
Options
Authentication Mode
MTU (bytes)
Next
Back
............................................................................................................................................................................................................................................................
6 - 24
Description
Select this option if VLAN ID is not being used.
Select this option if VLAN ID is used and enter the
VLAN ID number (between 2 and 4094)
Enter the user name for the PPPoE connection.If
you are not sure, please consult with your ISP for
more information.
Enter the password for the PPPoE connection.If you
are not sure, please consult with your ISP for more
information.
The access concentrator is optional. Please consult
with your ISP for information.
The service name is optional. Please consult with
your ISP for information.
Select this option to let the gateway connect to
Internet only when your trying to access it. If there
are no activities in the specified period (Max idle
time), gateway will disconnect the connection.
Select this option to let the gateway always
connected to the Internet.
Select and then click Connect to manually connect
the router to the Internet. Click Disconnect to
disconnect the connection.
Select the authentication mode from the drop-down
menu. Options include:
CHAP + PAP
•
Only MS-CHAP
•
Only CHAP
•
Only PAP
•
This is optional. Your ISP will provide this
information if it is necessary.
Select Auto to set the maximum transfer unit to the
default (1492), or enable Manual to manually enter
a value.
Click to go to next step.
Click to go back to previous page.
WAN PTM Connections
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
