Network
............................................................................................................................................................................................................................................................
Field
CMWP (CPE WAN Management
Protocol)
IGMP (Internet Group Management
Protocol) Proxy
Default Route
Add
Delete All
Edit
Delete
Port based binding
Port based mode enables you to bind ports to your WAN connection. You can bind LAN
ports 1 to 4 and WLAN SSID 1 to 4 in the WAN mode you selected. The default WLAN
SSID number is 1 and you can configure 2 to 4 in the
You can select the
proceed to the next configuration window.
In Port based mode, you can add up to four connections in routed mode.
Note:
connection in Static IP or DHCP mode and three connections maximum in PPPoE.
Note:
MAC based binding for any other connections.
The following WAN modes support port-based binding:
Static IP
•
DHCP
•
PPPoE
•
Bridge
•
Static IP
If you select
window with Port based binding opens; see
............................................................................................................................................................................................................................................................
6 - 6
radio button for each WAN mode and then click
Port Based
If you do not set a VLAN ID in the connections, you can only have one
If you already have a connection with Port based binding, you can not select
Static IP as the mode in the
Description
Provide remote control service. It will allow remote
ACS server to manage this gateway.
Provide service to be used for video streaming and
gaming.
Set the connection as the gateway of last resort,
every unknown packet will be forwarded via default
route.
Click to add the new connection and brings you to
next step.
Delete all connections below in the table.
Modify the connection setting.
Delete the connection.
WiFi Setting.
WAN PTM Connections
Figure 6-4.
WAN PTM Connections
to
Add
, the Static IP settings
