Alcatel-Lucent CellPipe 7130 Manual page 130

Telephony
............................................................................................................................................................................................................................................................
Table 12-4 Field descriptions
Field
Primary Codec
Secondary Codec
Tertiary Codec
Quaternary Codec
T.38 Fax
Max Bit Rate
Rate Management
FAX Pass Through
RTP Min Port
RTP Max Port
DTMF mode
Save
Clear
............................................................................................................................................................................................................................................................
1 2 -1 0
Description
A codec (coder/decoder) codes analog voice signals
into digital signals and decodes the digital signals
back into analog voice signals. Please select to give
the priorities of your codec.
Please select to give the priorities of your codec.
Please select to give the priorities of your codec.
Please select to give the priorities of your codec.
Check T.38 to let the device send fax messages
through IP networks.
Please select the maximum bit rate in bits per second
for your fax message.
Select the data rate management method.
Local data rate management requires that the
training signal be generated locally.
Network data rate management requires that the
training signal be transferred over network.
Network is the default value.
Select to allow Fax Pass Through method.
Enter the minimum port range of the RTP listening
port.
Enter the maximum port range of the RTP listening
port.
Please indicate how your device should handle the
tones that your telephone will make when you push
the phone buttons.Please consult your VoIP service
provider.
RFC 2833: Sending the DTMF tones in RTP
packets.
PCM: Sending the DTMF tones in the voice data
stream.
SIP INFO: Sending the DTMF tones in SIP
messages.
Click to save the call statistics and call log.
Click to clear the call statistics and call log.
RTP/Codec settings
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
