Qos Mac - Alcatel-Lucent CellPipe 7130 Manual

QoS PTM Setup
............................................................................................................................................................................................................................................................
Field
New Tos Value
New DSCP Value
Keep Cos value
New Cos Value
Align Cos with
Tos Value
Interface Name
QoS
Classification
TOS/DSCP
Setting
CoS Setting
Apply Changes

QoS MAC

The QoS MAC window enables you to configure QoS policy for specific device by MAC
address when the gateway is operating in bridge mode.
Select
............................................................................................................................................................................................................................................................
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
Description
Select New Tos Value and enter a queue number (0 to 7) to assign to the
incoming traffic.
Select New DSCP Value and enter a DSCP value (0 to 63).
Select Keep CoS value to retain the original value.
Select New Cos Value to set a new CoS (class of service) value for
incoming traffic.
Select Align Cos with Tos value to assign CoS (class of service) as Tos
value for incoming traffic.
The Interface name of WAN connection to configure its QoS policy.
The classification of this QoS rule:
Original Tos Tag - assign the queue according to the incoming
•
traffic's Tos value.
Specified Queue - incoming traffic will be queued in the specific
•
queue (0 to 7).
TOS/DSCP marking setting for incoming traffic.
Cos (class of service) setting of this QoS rule.
Click to save your changes.
in the
QoS MAC QoS Setup
menu to access the QoS MAC window; see
QoS MAC
Figure 10-7.
1 0 - 1 3
