Alcatel-Lucent CellPipe 7130 Manual page 100

QoS PTM Setup
............................................................................................................................................................................................................................................................
Field
Netmask
Interface
MAC Address
Destination
IP Address
Netmask
Protocol
Source Port
Destination Port
QoS Classification
Queue
ToS/DSCP
Remarking
CoS (p-bit)
Remarking
Add
Overview
Target
Source IP
Netmask
Source Port
Destination IP
Netmask
Destination Port
............................................................................................................................................................................................................................................................
1 0 -6
Description
Select the subnet mask of the source host.
Select the radio button and select a connection to configure its QoS policy.
Select the radio button and enter the MAC address.
Enter the IP address of the destination host.
Select the subnet mask of the destination host.
Click Select Protocol to choose a protocol.
Enter the range of source ports for this QoS policy.
Enter the range of destination ports for this QoS policy.
Select one of the following:
Original ToS Tag to assign the queue according to the incoming ToS
•
value.
Specified Queue and enter a queue number (0 to 7) to assign to the
•
incoming traffic.
Select one of the following:
Keep Original ToS/DSCP to retain the original value.
•
New ToS Value and enter a queue number (0 to 7) to assign to the
•
incoming traffic.
New DSCP Value and enter a DSCP value (0 to 63).
•
Select one of the following:
Keep CoS Value to retain the original value.
•
New CoS Value to set a new CoS value for incoming traffic.
•
Align CoS with ToS value to set CoS same as the ToS value for
•
incoming traffic.
Click to add the policy and save your changes.
Upstream or Downstream. Target 1 is the highest priority.
IP address of the source host.
Subnet mask of the source IP address.
Port number of the source host.
IP address of the destination host.
Subnet mask of the destination IP address.
Port number of the destination host.
QoS Policy
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
