Hardware installation

Overview
Purpose
This chapter provides the instructions to install the CellPipe 7130 RG hardware.
Contents
This chapter covers the following topic:

Mounting Procedure

To install the CellPipe 7130 RG
Mounting Procedure
There are multiple ways for mounting the CPE:
Wall Mounting
Pre-Requirements
Anchors
•
Screws
•
Drill & Drill bit
•
1. Locate a high position on the wall that is free of obstructions.
2. Connect two screws in the wall 5 cm(2 in.) apart. Do not screw the screws all the way
into the wall.
Important!
enough to hold the weight of the CPE. (recommended screw type and size: Nylon wall
plug (T8x25mm) and screws (T3.5x16mm)).
3. Align the holes on the back of the CPE with the screws on the wall.
............................................................................................................................................................................................................................................................
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
Make sure that the screws are securely fixed to the wall and strong
