Alcatel-Lucent CellPipe 7130 Manual page 43

Network
............................................................................................................................................................................................................................................................
Select
Connections window; see
Figure 6-3 WAN PTM Connections window
Table 6-3
Table 6-3 Field descriptions
Field
Interface Name
Mode
Binding
Port Based
MAC Based
No LAN/WLAN Binding
Local Service
VoIP
............................................................................................................................................................................................................................................................
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
WAN PTM Connections
Figure
describes the fields of the WAN PTM Connection window.
in the menu to access the WAN PTM
Network
6-3.
Description
Enter an appropriate name for your new connection.
Click the drop-down menu and select either Static
IP, DHCP, PPPoE, or Bridge as the connection
type.
Bind the interface by LAN or WLAN port
Bind the interface by physical MAC address
The interface does not bind to any Port or MAC
Provide VoIP service to be used.
WAN PTM Connections
6 - 5
