Network
............................................................................................................................................................................................................................................................
Fields
Password
Access Concentrator
Service Name
Mode
Connect on demand:
Max idle time
Always on
Manual
Options
Authentication Mode
MTU (bytes)
Next
Back
Activate WAN Settings
Delete All
Edit
Delete
Bridge
If you select
settings window with Port based binding opens; see
............................................................................................................................................................................................................................................................
6 - 12
Description
Enter the password for the PPPoE connection.If you are not sure,
please consult with your ISP for more information.
The access concentrator is optional. Please consult with your ISP
for information.
The service name is optional. Please consult with your ISP for
information.
Select this option to let the gateway connect to Internet only when
your trying to access it. If there are no activities in the specified
period (Max idle time), the gateway will disconnect the connection.
Select this option to let the gateway always connected to the
Internet.
Select and then click Connect to manually connect the router to
the Internet. Click Disconnect to disconnect the connection.
Select the authentication mode from the drop-down menu. Options
include:
CHAP + PAP
•
Only MS-CHAP
•
Only CHAP
•
Only PAP
•
This is optional. Your ISP will provide this information if it is
necessary.
Select Auto to set the maximum transfer unit to the default (1492),
or enable Manual to manually enter a value.
Click to go to next step.
Click to go back to previous page.
Click to activate the connection.
Click to remove all WAN connections.
Click to modify a specific connection.
Click to remove a specific connection.
Bridge as the mode in the WAN PTM Connections
Figure 6-7.
WAN PTM Connections
window, the Bridge
