Alcatel-Lucent CellPipe 7130 Manual page 14

Product overview
............................................................................................................................................................................................................................................................
LED
DSL 1 to 2
USB 1 to 2
HPNA (Only
for
6Vz.A4111)
WLAN
WPS
LAN 1 to 4
Phone 1 to 2
Message
Power
Notes:
* Slow flashing: LED flashes at the rate of 2 seconds on and 2 seconds off.
............................................................................................................................................................................................................................................................
1 - 4
Status Description
On DSL is operating.
Flashing DSL is training.
Off DSL is disconnected.
On A device is connected to the USB port.
Flashing USB port has data traffic.
Off No device is connected to USB port.
On HPNA interface is enabled and connected to a HPNA
device.
Flashing HPNA traffic is present.
Off HPNA interface is disabled or disconnected to any HPNA
device.
On Wireless function is enabled.
Flashing Data is being transmitted on the wireless link.
Off Wireless function is disabled.
On WPS is enabled.
Off WPS is disabled.
On Ethernet LAN port 1 to 4 is connected and active.
Flashing Network activity over the corresponding ports.
Off Ethernet LAN port 1 to 4 is not active.
On Phone 1 to 2 is connected.
Off No phones are connected.
*
Slow flashing Firmware upgrade in progress.
Off No firmware upgrade in progress.
On CellPipe 7130 RG is powered on.
Off Power is disconnected.
Description of LEDs and interfaces
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
