Alcatel-Lucent CellPipe 7130 Manual page 31

Status
............................................................................................................................................................................................................................................................
Table 5-3 Field descriptions
Field
DSL Firmware Version
Mode
Traffic Type
Status
Link Power State
Line Coding (Trellis)
SNR Margin(0.1dB)
Atternuation(0.1dB)
Output Power(0.1dBm)
Attainable Rate (Kbps):
Rate (Kbps)
MSGc (# of bytes in overhead channel
message)
B (# of bytes in Mux Data Frame)
M (# of Mux Data Frames in an RS
codeword)
T (# of Mux Data Frames in a OH sub-
frame)
K (number of bytes in DMT frame)
R
S
L
D (interleabver depth)
I (interleaver block size in bytes)
N (RS codeword size)
Delay (msec)
............................................................................................................................................................................................................................................................
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
Description
The version of firmware in use.
The modulation protocol
The channel type
This is the status of the DSL link.
Displays the power management state of the DSL
connection.
The Trellis Coding status of downstream and
upstream.
This is a signal-to-noise ratio (SNR) margin for
traffic going in both directions.
An estimate of the average loop attenuation
downstream and upstream.
The total output power in both directions.
This is the maximum achievable downstream rate.
The actual rate at which data is flowing in both
directions.
Number of bytes in overhead channel message
Number of bytes in Mux Data Frame
Number of Mux Data Frames in FEC Data Frame
Mux Data Frames over sync bytes
This is the number of data bytes in an DSL data
frame.
The number of redundant check bytes per Reed-
Solomon code word.
The length of the Reed-Solomon code word, in data
frames.
Number of bits in PMD Data Frame
The interleaver depth.
Number of bytes in interleaver block size
The size of RS codeword.
The delay, in microseconds, of the DSL connection.
DSL Link Status
5 - 5
