Device Table - Alcatel-Lucent CellPipe 7130 Manual

Status
............................................................................................................................................................................................................................................................
Field
INP (DMT symbol)
OH Frames
OH Frame Errors
Super Frames
Super Frame Errors
RS Words
RS Correctable Errors
RS Uncorrectable Errors
HEC Errors
OCD Errors
LCD Errors
Total Cells
Data Cells
Bit Errors
Total ES
Total SES
Total UAS

Device Table

The Device Table displays information about the device that has connected to the CellPipe
7130 RG.
Select
............................................................................................................................................................................................................................................................
5 - 6
Device Table in the Status
Description
INP:Impulse Noise Protection DMT:Discrete Multi-
tone
The number of overhead frames.
The number of overhead frame errors.
This is the total number of super frames.
The number of super frames received that had
errors.
This is the total number of Reed-Solomon code
words.
The number of Reed-Solomon code words with
correctable errors.
The number of R-S code words that had
uncorrectable errors.
The total number of header error checksum errors.
The number of out-of-cell delineation errors.
The total of lost-cell-delineation errors.
Total number of cells.
The number of data cells.
The number of Bit Error.
Total number of Errored Seconds.
Total number of Severely Errored Seconds.
Total number of Unavailable Seconds.
menu to access the Device Table; see
Device Table
Figure 5-4.
