Product overview

Overview
Purpose
This chapter provides an introduction to the physical aspects of the CellPipe 7130 RG
6Ve.A4111 and 6Vz.A4111 including safety precautions, prerequisites, and descriptions.
The CellPipe 7130 RG 6Ve.A4111 and 6Vz.A4111 will be referred to as CellPipe 7130
RG throughout the rest of this document.
Contents
This chapter covers the following topics:

Hardware introduction

Safety precautions
Prerequisites
Description of LEDs and interfaces
Hardware introduction
This CellPipe 7130 RG supports Ethernet-over-VDSL2 using one Ethernet data link that is
rated up to 100 Mb/s symmetrically. With its bridge functionality, it can connect to any
device equipped with a 10BASE-T or 100BASE-TX network interface card. It supports
WAN connection via telephone cable to VDSL switch. It also supports HomePNA, USB
storage, VoIP, and wireless local area network. For this purpose, it provides:
One VDSL port
•
Four Ethernet LAN ports (10/100BASE-TX)
•
One HPNA interface (Only for 6Vz.A4111)
•
Two USB ports
•
Wireless (802.11n)
•
Two FXS ports
•
............................................................................................................................................................................................................................................................
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
1-1
1-2
1-3
1-3
1 -1
