QoS PTM Setup
............................................................................................................................................................................................................................................................
Table 10-5
Table 10-5 Field descriptions
Field
SIP ALG QoS
Enable
Original Tos Tag
(First 3 bits of
DSCP)
Specified Queue
Keep Original
ToS
New ToS Value
New DSCP Value
Keep CoS Value
New CoS Value
Align Cos with
ToS Value
Apply Changes

QoS Defaults

The QoS Default window enables you to configure the default QoS policy for each WAN
connection.
Select
Figure
............................................................................................................................................................................................................................................................
3EQ-10422-AAAA-TCZZA
Edition 01 February 2011
describes the fields of the QoS ALG window.
Description
Select Enable to turn on the SIP ALG QoS. Select Disable to turn off the
SIP ALG QoS.
Select Original Tos Tag (type of service) to assign the queue according
to the incoming Tos value.
Select Specified Queue and enter a queue number (0 to 7) to assign to
the incoming traffic.
Select Keep Original Tos to retain the original value.
Select New Tos Value and enter a queue number (0 to 7) to assign to the
incoming traffic.
Select New DSCP Value and enter a DSCP value (0 to 63).
Select Keep CoS value to retain the original value.
Enable New Cos Value to assign CoS (class of service) for incoming
traffic.
Enable Align Cos with Tos value to assign CoS (class of service) as Tos
value for incoming traffic.
Click to save your changes.
QoS Defaults in the QoS Setup
10-6.
menu to access the QoS Default window; see
QoS Defaults
1 0 - 1 1
