UG-976

ORDERING INFORMATION

BILL OF MATERIALS

Table 5. Components List for Motherboard
Qty Reference Designator
4 C1, C6, C7, C9
7 C2, C5, C8, C10, C15, C16, C17
2 C3, C4
1 C11
4 EXT_REF_1, EXT_REF_2,
EXT_REF_3, EXT_REF_4
1 J1
1 J2
3 J3, J7, J8
1 J4
1 J5
1 J6
1 J9
1 J10
1 L1
1 LK5
2 LK6, LK7
4 REF1, REF2, REF3, REF4
1 R1
2 R2, R3
11 R5, R6, R7, R8, R9, R10, R11,
R12, R13, R14, R15
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U10
2 U11, U12
FEC refers to Farnell electronic component distributors.
1
2 GRM refers to Murata electronic component distributors.
Description
6.3 V, tantalum capacitor (Case A), 10 µF, ±20%
50 V, X7R, ceramic capacitor, 0.1 µF, ±10%
10 V, X5R, ceramic capacitor, 1 μF, ±10%
6.3 V, tantalum capacitor (case A), 4.7 µF, ±20%
Straight PCB mount, SMB jack, 50 Ω
Header, 2.54 mm, 2 × 8-way
Header, 2.54 mm, 2 × 5-way
Header, 2.54 mm, 1 × 6-way
Header, 2.54 mm, 1 × 8-way
3-pin terminal block
2-pin terminal block
Header, 2.54 mm, 2 × 4-way
120-way connector
Inductor, SMD, 600 Ω
6-pin (3 × 2), 0.1 inch header and shorting block
4-pin (2 × 2), 0.1 inch header and shorting block
10-pin (5 × 2), 0.1 inch header and shorting block
Resistor, surge, 1.6 Ω, 1%, 0603
SMD resistor, 100 kΩ, 1%, 0603
SMD resistor, 100 Ω, 1%, 0603
3.3 V linear regulator
32 kb I C serial EEPROM
2
5 V reference, 8-lead MSOP
Ultralow noise XFET® voltage reference
4.096 V reference
Dual op amp
Quad op amp
Op amp
Rev. A | Page 12 of 13
EVAL-AD5325DBZ User Guide
Stock Code/Part Number
FEC 1190107
FEC 1759122
GRM188R61A105KA61D
FEC 1432350
FEC 1206013
FEC 2308428
FEC 9689583
FEC 9689508
FEC 1766172
FEC 1667472
FEC 151789
FEC 1667509
FEC 1324660
FEC 9526862
FEC 148-535 and 150-411 (36-pin strip)
FEC 148-535 and 150-411 (36-pin strip)
FEC 1022227 and 150-411
FEC 1627674
FEC 9330402
FEC 9330364
Analog Devices ADP121-AUJZ33R7
FEC 1331330
Analog Devices ADR445ARMZ
Analog Devices ADR431BRZ
Analog Devices REF198ESZ
Analog Devices AD8616ARZ
Analog Devices AD8608ARMZ
Analog Devices AD8655ARMZ
1, 2
