Maintenance
How to calculate the running time of a motorized control valve
The running time of the motorized control valve is calculated using the following methods:
Seated valves
Running time = Valve stroke (mm) x actuator speed (sec. / mm)
Example:
Rotating valves
Running time = Turning degrees x actuator speed (sec. / degr.)
Example:
Nz (neutral zone)
Set the acceptable flow temperature deviation.
Set the neutral zone to a high value if you can accept a high variation in flow
temperature. When the actual flow temperature is within the neutral zone, the controller
does not activate the motorized control valve.
The neutral zone is symmetrical around the desired flow temperature value, i.e. half the
value is above and half the value is below this temperature.
26 | © Danfoss | 2016.05
5.0 mm x 15 sec. / mm = 75 sec.
90 degr. x 2 sec. / degr. = 180 sec.
Setting range
1 ... 9 K
6187
Factory setting
3 K
