Appendix A
Transmitter outputs
RS-232:
RS-422/485:
Receiver inputs:
RS-232:
RS-422/485:
Surge suppression option
Protocols and software
Management
IP configuration
Communication modes
Client OS support
Page 86
High Level Output:
Low Level Output:
Transmitter Skew:
Transmitter Outputs: 2 V (min) for 100 Ohm load
Transmitter Skew:
Distance:
Input Voltage Rating: –15 V to +15 V
Receiver Skew:
Input Voltage Rating: –15 V to +15 V Common Mode Input Voltage
Receiver Skew:
Surge suppressor is applied to each line; capable of sustaining up to
40-A peak, 8 x 20-µs transient surges, a clamping voltage of 30 V (RS-
232) or 15.5 V (RS-422/485), and a peak energy dissipation of 0.1
Joules.
Note: Units with the "SS" option are limited to 115.2 kbps due to
capacitive loading.
Quatech provides several ways to manage and configure SDS after
installation:
a. Windows Device Manager (Quatech Device Manager on
Windows NT4)
b. On-board utility accessible from a standard HTTP web
browser.
c. Simple Network Management Protocol (SNMP)
d. IntelliSock TCP socket services
UDP, TCP/IP, HTTP, DHCP, ARP, SNMP
DHCP, Static IP (set through SDS Installation Wizard) or custom
UDP datagram utility
Normal, Tunneling, Raw TCP, Auto TCP, Raw UDP
Device drivers provided for Windows 2000, Windows XP, Windows
NT4, and Linux
Other operating systems supported by IntelliSock TCP socket
services
Check Website for latest OS support information
940-0183-154
+5 V (min), +5.4 V (typical)
–5 V (min), –5.4 V (typical)
50 ns (typical), 200 ns (max)
5 ns (typical), 10 ns (max)
4000 feet
120 ns (typical), 250 ns (max)
13 ns (typical)
