Quatech SDS User's Manual
Step 11 Enter the WEP Keys in hex.
Step 12 Press Submit to configure the SDS with
your settings.
Note: Press the browser's Back button to make
no changes to the original settings.
Step Procedure
Step 13 Click on the link to reset the SDS.
Step Procedure
Step 14 Press Reset to activate your settings.
Step Procedure
Step 15 Close and reopen the browser.
Enter the new IP address in the URL
address block.
October 2006

Figure 44 - IP Address Successful screen

Figure 45 - Remote Reset screen

Figure 46 - SDS is now resetting screen

940-0183-154
Configuring the SDS using a Web interface
These are two digit hex values that will
be used for the WEP keys. Valid
characters are 0-9, a, b, c, d, e, and f.
The IP Address Update successful screen
displays. You must reset the SDS for
your changes to take effect.
If you press the browser's Back button,
your original settings remain unchanged.
Description
The Remote Reset screen displays.
Description
The SDS is now resetting screen
displays.
Description
This confirms that the SDS is accessible.
Page 51
