Quatech DSCLP-100 Specifications

The perfect solution for adding multiple high-speed serial ports to any
PC, Server, Thin Client or Embedded System
Q
uatech Low Profile PCI boards provide truly
universal connectivity, enabling a single product to
be used to implement systems with dramatically
different resource requirements. This makes
Quatech boards the most robust, most flexible, and
most economical choice for any application
requiring multiple serial ports.
Quatech boards use a universal PCI connector
compatible with both the 3.3V connector key
required by the PCI 2.3 and later specification and
the 5V connection used by older systems. They are
designed on the smallest MD1 Low Profile
footprint, but come with both a full size ORB for
standard systems, and a smaller ORB for use in Low
Profile backplanes to fit even 2U racks without riser
cards. In addition, our wide range of OS options
facilitates both system upgrades and multiplatform
installations.
Universal
Boards
■
One, two or four independent serial ports
■
RS-232 or RS-422/485 boards
■
Auto enable/disable RS-422/485 transmitter
■
Universal PCI connector, 3.3V and 5V
■
MD1 Low Profile PCI board (fits 2U racks)
■
Speeds up to 921.6 kbps
■
16550 UARTs with 16-byte FIFOs (1,2,4 port)
■
16750 UARTs with 64-byte FIFOs (8 port)
■
All ports share a single PCI interrupt
■
Win. 95/98/Me/NT/2000/XP/Vista, LINUX , DOS
■
Five year warranty
■
RoHS compatible
www.quatech.com
PCI
Serial
