Installing the device drivers
Figure 42 displays when the
IP connection test fails. It
presents you with these three
options:
Change the SDS' IP
configuration and retest
Move the SDS to a
different location and retest
Ignore the problem and
continue installing
Step Procedure
Step 55 Select one of the following options:
Correct the SDS network
configuration and retest. Press Next to
continue.
Move the SDS to a different subnet
and retest. Press Next to continue.
Ignore the problem and continue
installation. Press Next to continue.
Page 44

Figure 41 - Network Connectivity Test Failed screen

940-0183-154
Quatech SDS User's Manual
Description
Click Back to retest current configuration.
If you are not sure of the configuration
parameters, consult your system
administrator. The Internet Protocol
(TCP/IP) Properties dialog box displays.
Go to □ Step 32.
Check with your system administrator
for the subnet address. The Locate the
Serial Device Server on remote subnet
screen displays. Go to □ Step 45.
The TCP/IP Network Configuration
Parameters screen displays.
Go to □ Step 16.
