Quatech SDS User's Manual
Figure 16 shows the Restart
confirmation pop-up box.
Step Procedure
Step 20 Press OK to restart the SDS and make
your changes active.
Figure 17 warns you that the
SDS needs time to reset. Wait
until the Status LED glows
green, and then press OK.
Step Procedure
Step 21 When the Status light glows green, press
OK.
October 2006

Figure 15 - Restart confirmation pop-up box

Figure 16 - Information pop-up box

940-0183-154
Installing the device drivers
Description
The SDS reboots and takes on the new
configuration. The Information pop-up
box displays. Continue with □ Step 21.
Description
The glowing Status light indicates that
the SDS is ready. The TCP/IP Network
Configuration Parameters screen displays.
Continue with □ Step 22.
Page 23
