Quatech SDS User's Manual
Step Procedure
Preliminary Click on Serial Ports in the selection
Step bar.
Note: Setup screens vary slightly between
RS-232 and RS-232/422/485 (MEI) units.
If you have an RS-232/422/485 (MEI) SDS,
the Configure Serial Port Interface step will
display so that you can select between RS-
232 and RS-422/485 operation.
If you have an RS-232 SDS, the Configure
Serial Port Interface step will not display
and you will not be presented with any RS-
422/485 configuration options.
October 2006
Auto TCP Timeout is used only in Data mode, not in the DSR
mode.
940-0183-154
Configuring the SDS using a Web interface
Description
The Serial Port Setup screen shown on
the following page displays.
Note: Click on a link to see a pop-up help
screen for that item. For example, if you
click on the Auto TCP mode link, the
following help screen pops up.
Page 65
