Configuring the SDS using a Web interface

Setting SNMP parameters

Note: Only SDS devices with a
firmware revision level of 5.0
and above can support SNMP.
Step Procedure
Preliminary Click on Network in the selection bar
Step and then select SNMP Setup from the
left panel.
Step Procedure
Step 1 Enable or disable SNMP in the SDS.
Select the Enable SNMP checkbox to
enable SNMP. Continue with
Clear the checkbox to disable SNMP.
Go to
Step 2 Enter the System Group information.
Contact:
Location:
Step 3 Enter the Management Host/Trap
Page 52
SDS devices with firmware revision 5.0 and higher have been
enhanced with additional Flash RAM to support SNMP. Older
hardware does not have sufficient memory to store the SNMP agent.
To determine the firmware revision level of an SDS, navigate to the
Home page in the Web-based interface (see page 45). The F/W
revision level is shown at the bottom of the Home page.

Figure 47 - SNMP Setup screen

□ Step 5.
940-0183-154
Description
The SNMP Setup screen shown on the
following page displays.
Description
By default, SNMP is disabled and the
checkbox is cleared.
□ Step 2.
The Contact should be the person
responsible for the operation of the SDS.
The Location could be as general as Italy
or as specific as the 3
Note: The System Group Description is the
same as the SDS Descriptive Name, which
you can set on the Administration screen.
Quatech SDS User's Manual
floor storage closet.
rd
