Quatech SDS User's Manual
Figure 35 explains how to
connect the SDS to
computer for location
configuration purposes.
Step Procedure
Step 43 Connect the Ethernet port on your SDS to
the Network Interface Connection (NIC)
on your computer. Either a crossover
patch cable or a "straight through" cable
will work.
Step 44 Connect power to the SDS and confirm
that it is ready to proceed.
Press Next to continue.
October 2006

Figure 34 - Locate the Serial Device Server using direct discovery screen

your
and
940-0183-154
Installing the device drivers
Description
Continue with □ Step 44.
The Status LED should glow green.
The Search network for Serial Device
Drivers screen displays.
Go to □ Step 10.
Page 37
